0.3mm Silicone Coated Fiberglass Fabric Heat Insulating Materials

0.3mm Silicone Coated Fiberglass Fabric Heat Insulating Materials
0.3mm Silicone Coated Fiberglass Fabric Heat Insulating Materials 0.3mm Silicone Coated Fiberglass Fabric Heat Insulating Materials 0.3mm Silicone Coated Fiberglass Fabric Heat Insulating Materials 0.3mm Silicone Coated Fiberglass Fabric Heat Insulating Materials 0.3mm Silicone Coated Fiberglass Fabric Heat Insulating Materials 0.3mm Silicone Coated Fiberglass Fabric Heat Insulating Materials 0.3mm Silicone Coated Fiberglass Fabric Heat Insulating Materials 0.3mm Silicone Coated Fiberglass Fabric Heat Insulating Materials 0.3mm Silicone Coated Fiberglass Fabric Heat Insulating Materials 0.3mm Silicone Coated Fiberglass Fabric Heat Insulating Materials 0.3mm Silicone Coated Fiberglass Fabric Heat Insulating Materials 0.3mm Silicone Coated Fiberglass Fabric Heat Insulating Materials
Basic Information
Place of Origin: China
Brand Name: Unionfull
Certification: ISO9001:2008, SGS
Model Number: UPSE-8628D80
Minimum Order Quantity: 500 Meters
Price: $2.6-3.50/ Square Meter
Packaging Details: 50 meters per roll with poly bag
Delivery Time: 15 Working Days After Receiving Payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 50000 square meters per day
Get Best Price Contact Now
Base Cloth: 7628 Fiberglass Fabric Coating: 80g Grey Silicone
Total Thickness: 0.3mm Total Weight: 280g/m2
Width: 100cm Weave: Plain Weave
Alkali Content: Free Roll Length: 50m
Highlight:

thermal insulation blankets

,

thermal insulation jackets

0.3mm Silicone Coated Fiberglass Fabric For Thermal Insulation Materials





Fire resistant silicone coated fiberglass fabric is a woven e-glass glass fiber cloth which heavily coated with the compound of grey silicon/rubber. The coated fiberglass fabric sheds molten metal splash so there is very little heat transfer.

Silicone coated fiberglass fabric is a great choice for thermal insualtion and electrical insulation application such as protection of industrial hydraulic hoses and lines, fuel & oil lines, wires, cables, tube and pipe from exposure to extreme heat conditions. The special formulation of silicone rubber coated fiberglass fabric sheds molten metals, welding splatter, electrical or grinding sparks. Silicone coating also provides protection from ozone, UV and abrasion.


Technical Data :


Style Weave Yarn Thickness Weight Width
7628 Plain

G75 1/0 0.7Z

G75 1/0 0.7Z

 0.2mm 200g/m2 1.55m




Specification Of UPSE-8628D80:

Item Silicone Coated Fiberglass Fabric
Material E-glass Fiber Glass
Weave Plain
Count 17.3/13 Ends/CM
Yarn

G75 1/0 0.7Z

G75 1/0 0.7Z
Mass Per Unit 280g/m2(200+80)
Thickness 0.3mm
Width 100cm
Working Temperature

Silicone Coating below 260℃


Properties:


  • Anti-chemical, corrosion resistance
  • Excellent abrasion resistance and rigidity
  • Electric insulation
  • High strength, tear resistance, abrasion resistance
  • Maintain wide operating temperature extremes from -50 degree to 260 degree.
  • Different colors available



Application:


  1. Cold protection covers
  2. Fire doors, fire curtains, fire blanket
  3. Expansion joints, fabric connector
  4. Electrical insulation cover for generator
  5. Wire insulation, heating cable, ignition systems, relay leads and aircraft wire heat/electrical insulation

0.3mm Silicone Coated Fiberglass Fabric Heat Insulating Materials 00.3mm Silicone Coated Fiberglass Fabric Heat Insulating Materials 1
